Thermal vision scopes Dedal-TA2.331.2xA

Thermal vision scopes Dedal-TA2.331.2xA

Dedal-TA2.x is a thermal vision device intended for supervision over objects having thermal radiation under any conditions of illumination (day, night, twilight), including, under any weather conditions (a rain, fog, snowfall, etc.). The principle of the device operation is based on transformation of infrared radiation from objects of supervision and its representation in a look, convenient for perception. Also there is a possibility of changing of the color schemes of the image processing - "the hot black", "the hot white", etc. For the comfort of using, the device has a low battery indicator.

(21%): 9 371,99
7 745
: out of stock
ks
  • Long range of vision
  • Low battery indicator
  • Compact / Lightweight
Detector
Resolution, pixel     336x256
Rate, Hz       9
Detector step, μm     17
Type,        Uncooled microbolometer (FPA)
Spectral sensitivy range,   from 8 to 14
Calibration way     mechanical shutter/without shutter

Objective
Focus distance     50mmF/1.2
Field of view angle     6.5x5.0
Optical magnification   2.0

Image Terminal Module
Matrix type     AMOLED
Resolution, Pixel     800x600

Power Supply
Power source type     CR123, RCR123
Power source quantity, pc.   2
Voltage, V     6

Physical Characteristic
Dimension, mm     250x70x75
Weight, kg     0.60

Operational Characteristic
Operating temperatures, °C   from -30 to +50
Relative humidity,      98
Batery life, h     4
